Description

SEEK NEW HEIGHTS

With the R-605FA, immersive sound comes alive from all directions, including overhead, enabled by Dolby Atmos®. Add them to any monitor or tower speaker, or use as surround speakers for a hemisphere of rich, detailed sound.

ELEVATION BUILT-IN

Not just your typical full-range tower speaker, the R-605FA features a high performance up-firing Dolby Atmos speaker integrated in the top for an enveloping soundstage. It's a perfectly matched setup that virtually disappears.

ALL NEW 90° X 90° TRACTRIX® HORN

An updated horn design, including increased outer horn dimensions, will deliver more power and emotion to your music and movies. Bigger definitely means better, with directivity control over a larger bandwidth of frequencies, resulting in a more accurate sound stage.

LINEAR TRAVEL SUSPENSION (LTS) ALUMINUM TWEETER

A hallmark of Klipsch speakers, the exclusive 1" LTS with Kapton Suspension tweeter minimizes distortion in the R-605FA for more detailed performances. Aluminum is an extremely light and rigid material used in the tweeter assembly to provide high efficiency.

SPUN-COPPER THERMOFORMED CRYSTALLINE POLYMER WOOFERS

Utilizing trickle-down technology from Klipsch's highly acclaimed Reference Premiere series of speakers, the 6.5" TCP woofers have steeper angling of the cones for a smoother response and improved accuracy and transparency.

REAR TRACTRIX PORT

The rear Tractrix port is perfectly matched to the cabinet and woofers, creating ideal airflow with minimal distortion or turbulence even at the lowest frequencies.

HIGH-QUALITY CABINET DESIGN & APPEARANCE

Hidden fasteners, edge-to-edge horn, and low-profile magnetic grilles give the speakers a polished, modern appearance. MDF cabinets with scratch-resistant, textured wood grain to fit right into your home décor.

REFERENCE REDEFINED

Check out all of the speakers in the newest generation of the legendary Klipsch Reference series speakers and prepare to have your world rocked.



Specification

• FREQUENCY RESPONSE: 38Hz - 21kHz +/- 3dB

• SENSITIVITY*: 96 dB (In-Room)

• POWER HANDLING (CONT/PEAK): 100W/400W

• NOMINAL IMPEDANCE: 8 ohms Compatible

• CROSSOVER FREQUENCY: 1,440 Hz

• HIGH FREQUENCY DRIVER: 1" Aluminum LTS tweeter mated to a 90 x 90 square Tractrix® Horn

• LOW FREQUENCY DRIVER: Dual 6.5" spun-copper TCP woofers

• ENCLOSURE MATERIAL: MDF

• ENCLOSURE TYPE: Bass-Reflex via rear-firing Tractrix®ports

• INPUTS: Single Gold Plated Binding Posts

• HEIGHT INCHES (MM): 40" (1017 mm)

• WIDTH INCHES (MM): 9.4" (240 mm)

• DEPTH INCHES (MM): 15.2" (386 mm)

• PRODUCT WEIGHT LBS (KG): 41 lbs (18.6 kg)
