Pickup Cartridge and Stylus
Pickup Cartridge: SMMC 20 CL (Moving Micro Cross principle) Stylus: Nude Contact Line Diamond Recommended tracking force: 1.3 g
Tonearm
Tangential tracking
Frequency range
50, 60 Hz
Playback Speed
33 & 45 rpm
Controls
Automatic pickup movement Automatic record-size Automatic speed selection Electronic lift system Dial for speed: 2 pointers Drive system: Belt
Wow and flutter
Wow and flutter, DIN: <± 0.05 % Wow and flutter, WRMS: <± 0.025 %
Rumble
Rumble DIN unweighted: > 42 dB Rumble DIN weighted: >65 dB Speed deviation: < 0.02 % Speed control range: > 6 % Dial for speed: 2 pointers Drive system: Belt
Motor
Controlled synchronous
Stylus pressure range
Stylus pressure range: 0 - 1.5 gram Channel Separation 1000 Hz: > 25 dB Channel Separation 400 - 10.000 Hz: > 20 dB Channel difference: < 1.6 dB Intermodulation: < 1%
Designer
Jacob Jensen
Materials
Oak Wood Stainless Steel Aluminium
Weight
12 kg
Dimensions
49 w x 10 h x 38 d cm
Dust Cover
Hinged and detachable
Power Supply
110 + 130 + 220 + 240 volts
Power consumption
40 watts
Power Frequency
50 + 60 Hz
Wired Outputs
DIN 5-pin Line out
Compatibility
Beogram 4000c is compatible with all Bang & Olufsen speakers excluding Bluetooth portable speakers. Beolab 20, Beolab 18 and Beolab 17 can connect to Beogram 4000c via Beosound Core.
